Cov Khoom Siv Ethanol Cov Khoom Siv yog cov kev siv hluav taws xob, thiab lwm yam kev txhawb nqa kev ua kom zoo dua qub
Cov tseem ceeb ntawm ethanol extraction khoom
1. high-efficiency, ntse extraction
Siv cov khoom siv hluav taws xob-tam sim no tam sim no los ua kom ethanol rov ua haujlwm los ntawm 40%, ua tiav cov kev rho tawm nce mus txog 98%.
2.}} yoog yoog rau ntau yam xwm txheej
Tau tshaj ethanol, methanol, acetone, thiab lwm yam solvents .
Muaj cov qauv dynamic / zoo li qub rau cov khoom siv sib txawv, suav nrog tshuaj ntsuab, khoom noj khoom haus, thiab biomass .
3. nyab xeeb, lub zog-txuag qauv
Tsim nrog 316L stainless hlau rau corrosion tsis kam thiab tu yooj yim; Ua raws li GMP / FDA ntawv pov thawj .
Features a three-stage condensation recovery system with >92% ethanol rov qab, txo kev siv hluav taws xob .
4.} modular customization
Customizable tuav tau muaj peev xwm (50l-5000l) nrog conical, ncaj, lossis lwm yam qauv tsim .
Yeem Add-ons: Ua ntej tso tsheb hlau luam, chillers, thiab tawg cov tshuab rau tsawg-ethanol extraction.
Lub ntsiab parameter
1) ntim: tsawg kawg 50l;
2) Khoom siv: SS304 lossis SS316;
3) Cov qauv ntawm Extractor: peb txheej qauv nrog cov duab sib txawv, xws li: Hom ncaj, inverted khob, thiab lwm yam}
Qauv
|
Tus qauv |
Sd500 |
Sd1000 |
Sd2000 |
Sd3000 |
Sd5000 |
|
Tag Nrho Ntim (L) |
600 |
1200 |
2300 |
3300 |
5400 |
|
Siab (Bar) |
1) Sab hauv siab yog cov huab cua siab; 2) lub siab ntawm lub tsho yog 3bar |
||||
|
Od ntawm manhole (mm) |
300 |
400 |
400 |
400 |
600 |
|
Od ntawm outlet rooj (hli) |
400 |
600 |
800 |
800 |
1000 |
|
Chaw sov cua sov (m2) |
2.4 |
3.1 |
4.2 |
5.5 |
7.1 |
|
Cua txias thaj chaw (m2) |
3 |
5 |
5 |
8 |
10 |
|
Pom thaj chaw (m2) |
0.25 |
0.25 |
0.25 |
0.25 |
0.5 |
|
Chav yuav tsum tau (KG / H) |
245 |
325 |
345 |
645 |
720 |
|
Tsab ntawv |
Cov ntaub ntawv saum toj no yog rau siv |
||||
Ethanol Extraction Khoom Siv Khoom Siv
Kws Tshuaj:Extraction ntawm cov tebchaw nquag (alkaloids, flavonoids, cbd) .
Ua Zaub Mov Ua Noj:Kev tsim cov duab ntuj, cov roj tseem ceeb, thiab oleoresins .
Cov tshuaj pleev ib ce:Purification ntawm cov nquag peptides thiab collagen .
Kev Tshawb Fawb & Kev Tsim Kho:Lab-teev cov khoom siv rau cov txheej txheem optimization .
Vim li cas thiaj ntseeg tau peb cov khoom siv rho tawm cov khoom siv?
✅ Xaus-to-to-xaus kev txhawb nqa: kev tsim qauv, kev teeb tsa, kev kawm, thiab tu nrog lub neej kev pab.
Tus nqi efficiency: 50% qis peev thiab kev ua haujlwm yooj yooj yim piv rau cov kev faib tawm supercritical.
Seb puas tsim cov kab ntau lawm lossis txhim kho cov khoom siv uas twb muaj lawm, peb txoj kev tiv thaiv tau ua ntej, kev tu siab lub sijhawm, thiab kev ua haujlwm sib txawv, thiab cov kev daws teeb meem customized, thiab cov kev daws teeb meem customized.
